TASER X26 – The Workhorse TASER ECD (Electronic Control Device)

The TASER X26 ECD has transformed law enforcement and becoming a vital tool for patrol level law enforcement officers around the world. The X26 provides a wide variety of benefits to users.

Easy to Use

• 60% smaller in size and weight than the ADVANCED TASER M26 ECD
• Optimized for full-time carry on the duty belt
• Software upgradable
• Integrated LASER sight with low intensity lights
• Central Information Display (CID) indicates countdown timer during an activation and battery level

More Effective

• Greater incapacitating power than the ADVANCED TASER M26 ECD

Quality and Reliability

• Used in the field today and ready for you

Features

Neuro Muscular Incapacitation (NMI)

The key technology to disable even the most aggressive subjects, NMI temporarily overrides the command and control systems of the body to impair muscular control.

Shaped Pulse™ Technology

A sophisticated pulse wave that utilizes a high voltage leading edge to penetrate barriers such as clothing around the body followed by a lower voltage stimulation pulse to cause Neuro Muscular Incapacitation.

Digital Pulse Control (DPC)

A digital controller that constantly adjusts the power throughout the TASER power supply system to maintain a consistent pulse rate (usually 19 pulses per second) across a broad spectrum of operating conditions.

TASER Cartridge

A replaceable module that allows for the engagement of targets at ranges up to 35 feet (10.6 meters). Integrates a nitrogen propulsion system, insulated TASER wire, probes, and AFID serialization. Compatible with both the TASER M and X models.

Anti-Felon Identification (AFID)

A system to deter misuse through enhanced accountability, AFID includes bar-coded serialization of each cartridge and disperses confetti-like ID tags upon activation.

Enhanced USB Dataport

Second generation dataport technology captures time and date of each device activation, as well as additional data such as duration of application, temperature, battery status, and automatic conversion from GMT to local time zones. Allows for plug-and-play download via USB connection.

LASER and Illuminator Integration

User configurable settings control LASER and low-intensity illumination synchronous with safety switch operation.

Digital Power Magazine (DPM™) Battery Pack

Integrated power source with lithium battery cells and solid state memory module for tracking power consumption, power levels remaining, and allows for software updates to be distributed via battery replacement.

Central Information Display (CID)

Digital display that communicates battery percentage, duration remaining during pulse discharge, time, and date.

Specs

Physical Characteristics
Dimensions w/o cartridge (L x W x H)	6.0″ [15.2 cm] x 1.3 [3.3 cm] x 3.2″ [8.1 cm]
Weight	7.2 oz [204 g]
Dimensions w/ cartridge (L x W x H)	7.3″ [18.5 cm] x 1.3 [3.3 cm] x 3.2″ [8.1 cm]

Detailed Specifications
Housing	High impact polymer
Operating temperature range	-4 °F [-20 °C] to 122 °F [50 °C]
Operating relative humidity	up to 80% (non-condensing)
Estimated useful life	Approximately 5 years

Available Options*
Option	Description
X26 Handle Colors	Black Clear
Grip Plate Colors	Black Silver
Holsters	Blade-Tech Tek Lock Level II with Thumb Break (Right or Left) BLACKHAWK SERPA Level I with Trigger Finger Release (Right or Left)
Power Sources	DPM XDPM

Product Warranty

TASER Product Warranty - LETASER Product Warranty - LE Non US

*Options shown are only a subset of available packages and options. Please call or contact TASER International for full SKU listings, options, accessories, and pricing.

Feature Matrix
